TSK1048 — DMX cable digital audio+Power 1x2x0,22+3x0,75

Description

Professional special hybrid cable composed of a 2x0.22 mm² tinned O.F.C. copper 110 Ohm AES/EBU digital audio line and three 0.75 mm² red O.F.C. copper power conductors with a PVC outer jacket. Thanks to the combination of signal and power in a very compact outer diameter, this cable combines excellent transmission clarity with the convenience of single cabling, making it the ideal choice for audio-lighting rental companies and integrated system installers.

Purpose and Usage: This cable is specifically designed for connecting active loudspeakers, stage monitors, motorized spotlights, and LED bars that simultaneously require electrical power and DMX control or digital audio signals. It is used for making mobile extensions and quick wiring in theaters, conference rooms, concerts, and live events where it is necessary to optimize setup times and reduce cable clutter on the ground. Its structure is well-suited for termination with standard power plugs and metal XLR connectors without the need for special tools.

Features and Versatility: The extraordinary versatility of the product stems from the separate management of the internal sections, with the data line protected by a fire-retardant PVC jacket and a 100% covering red copper spiral shield that isolates the signal from mains electricity interference. The highly flexible overall PVC jacket is designed to withstand frequent coiling in the field without compromising laying agility. It is the ultimate solution for system integrators and lighting designers who require an agile, robust, and pleasant-to-touch "all-in-one" interconnection.
